Description
Solid billet construction and complete with all necessary hardware this clutch slave is exactly what any off-road Dune Buddy or Sandrail needs!
This Hydraulic Clutch Slave Cylinder Fits Beetle And Bus style Transmissions.
Features:
Compatible with all hydraulic pedal assemblies.
Machined flat spots for wrenches allowing easy rebuilds.
Aluminum body tapped 1/8 inch NPT In two locations.
Includes two fittings - one female 3/8 inch-24 and 1/8 inch NPT with bleeder.
Note: Proper alignment is critical for long life of this item.
Brackets and heim joint kits are available for easy installation and smoother operation.
Search the following part numbers for acciated parts.
C13-17-2814 Slave Bracket, Type-1 Beetle Tranmission.
C13-17-2883 Billet Slave Bracket, Type-1 Beetle Tranmission.
C13-17-2813 Billet Slave Bracket, Type-2 Bus Tranmission.
C13-17-2817 Heim End 3/8 inch-24 Threads, 3/8 inch Ball, for EMPI or Cip1 Slave cylinder.
C13-17-2818 Heim End 3/8 inch-24 Threads, 5/16 inch Ball, for CNC Slave cylinder.
Also see Cip1 Slave cylinders.
C26-798-560 - Heavy Duty Billet replacement clutch slave cylinder - for Type-1 Beetle style transmission.
C26-798-561 - Heavy Duty Billet replacement clutch slave cylinder - for Type-2 Bus (091) style transmission.
